PVC Pipe Fittings
Solvent-weld uPVC fittings matched to the pipe class, so the joint is as strong as the wall it sits in. Elbows, tees, reducers, couplings, caps and threaded adaptors.
Tell us the size and quantity — price, lead time and loading plan back in one working day
Dial in the pressure class first, then the diameter. If you are unsure, send the working pressure and we will recommend the SDR.
Fittings are quoted as a set, not as single pieces
A line needs elbows at every change of direction and tees at every branch. We quote the fittings against your pipe schedule so the counts match the drawing.
| Family | Sizes | Note |
|---|---|---|
| Elbow 90° / 45° | DN20–DN315 | Equal and reducing |
| Tee | DN20–DN315 | Equal and reducing branch |
| Coupling / repair | DN20–DN315 | Slip and repair types |
| Reducer bush | DN25–DN315 | Spigot × socket |
| Threaded adaptor | DN20–DN110 | BSP or NPT, brass-reinforced on request |
| Union / valve body | DN20–DN110 | For serviceable joints |
Sizes shown are the working range; the exact size list per family is issued with the quotation because mould ranges differ between families.
Solvent welding, done properly
- Cut square, chamfer, and wipe the socket and spigot clean
- Apply cement to both surfaces, not just the socket
- Push home and hold 30 seconds, do not twist after contact
- Allow the joint to cure before pressure testing — longer in cold weather
What to send with an enquiry
The pipe schedule with diameters and the number of direction changes is enough for us to build a fitting list with counts, instead of you ordering piece by piece.
Send the pipe schedule
We return a fitting list with counts and a packing plan.
Questions on this product
Do fittings match both PN10 and PN16 pipe?
Yes — the fitting is selected to the pipe class, so state the class when ordering.
Are threaded inserts available?
Brass-reinforced threaded adaptors are available on request; plain plastic threads are standard.
Can you supply a mixed carton?
Yes, cartons can be mixed across sizes within a family to fill a pallet.
What is the MOQ?
Confirmed on quotation — usually quoted together with the pipe.]
