Butt Fusion Welding Machine
Manual and hydraulic butt fusion machines for site jointing of PE pipe, 63–315 mm, with heating plate, planing tool, clamps and a parameter chart by wall thickness.
Tell us the size and quantity — price, lead time and loading plan back in one working day
Dial in the pressure class first, then the diameter. If you are unsure, send the working pressure and we will recommend the SDR.
Match the machine to the diameter range you actually weld
Buying one machine for the whole range usually means a heavy unit on small pipe. Two machines — or a machine plus a coupler set — is often cheaper on site.
Typical configurations
- 63–200 mm manual, for laterals and small mains
- 90–315 mm hydraulic, the usual workhorse
- 200–500 mm hydraulic with crane lifting points
- Electrofusion control unit for couplers and saddles
What ships in the case
- Heating plate with thermometer
- Planer / facing tool
- Clamp inserts for each size step
- Parameter chart by wall thickness
- Spare seals and fuses
Model list, motor rating and case dimensions are confirmed on the datasheet with the quotation — the capacities above are the configurations we quote most often.
Why buy the machine with the pipe
A crew that has never welded PE will produce a joint that fails a pressure test, not a joint that looks wrong. Shipping the machine with a parameter chart matched to the pipe order removes the most common field failure.
Training material
Step-by-step fusion procedure, bead size photos and a checklist per joint are supplied as PDF; we can review your procedure against the machine you already own.
Tell us the diameter range and voltage
Say whether you need 220 V single phase or 380 V three phase, and how many crews will share the machine.
Questions on this product
Which capacity should I take?
Size it on the largest diameter you weld regularly, not the largest you might weld once — a 315 machine on 63 mm pipe is slow and heavy.
Do you supply spares?
Heating plates, thermometers, seals and fuses can be quoted with the machine or as a spares kit.
Is training included?
Written procedure and video are included; on-site training depends on the destination and is quoted separately.
What is the lead time?
[To confirm.]
